Energy-Efficient Heavy-Duty Belt Conveyor Machine - Customizable Conveyor System for Mining & Bulk Material Handling
Datos del producto:
| Lugar de origen: | Porcelana |
| Nombre de la marca: | OSMANUV |
| Certificación: | ISO9001 |
| Número de modelo: | Especificación |
Pago y Envío Términos:
| Cantidad de orden mínima: | 1 juego |
|---|---|
| Precio: | Negociable |
| Detalles de empaquetado: | Envasado de madera |
| Tiempo de entrega: | 30-45 días |
| Condiciones de pago: | T/T |
| Capacidad de la fuente: | Negociación |
|
Información detallada |
|||
| Ancho del cinturón: | 300 mm - 2000 mm (hasta 2400 mm personalizable) | Longitud del transportador: | 5 m - 100 m (cualquier longitud personalizable) |
|---|---|---|---|
| Velocidad de transmisión: | 0 - 30 m/min (0 - 80 m/min personalizable) | Capacidad de carga: | 50 kg/m - 200 kg/m (hasta 500 kg/m personalizable) |
| Material de correa: | PVC-120 / PU / Caucho / Silicona / Plástico modular (grado FDA opcional) | potencia del motor: | 0,75 kW - 22 kW (personalizable) |
| Ángulo de la pendiente: | 0° - 24° (hasta 90° con correa con listones) | Temperatura de funcionamiento: | -10°C - +50°C (cinturón resistente al calor/frío personalizable) |
| Resaltar: | heavy-duty belt conveyor machine,customizable conveyor system for mining,energy-efficient bulk material handling conveyor |
||
Descripción de producto
Heavy-Duty Belt Conveyor Machine for Mining & Bulk Material Handling | Customizable Conveyor System
Product Description
A belt conveyor machine is a continuous material handling equipment that uses an endless belt stretched over pulleys to transport bulk materials, packaged goods, or assembly components from one point to another. It operates on the friction principle between the drive pulley and the belt surface, enabling smooth, efficient, and low-noise movement.
This conveyor system is widely used in mining, cement, food processing, logistics, warehousing, packaging, and manufacturing industries. It supports horizontal, inclined, or declined transport and can handle materials ranging from fine powders and grains to heavy ores, boxes, and parts.
Our belt conveyor is designed for high durability, low maintenance, and easy integration into existing production lines. Every configuration — belt type, width, length, speed, motor power, and material — is fully customizable to your specific application.
Technical Parameters (Table Format)
| Parameter | Standard Range | Customizable Option |
|---|---|---|
| Belt Width | 300 mm – 2000 mm | ✔ Yes (up to 2400 mm) |
| Conveyor Length | 5 m – 100 m (standard) | ✔ Yes (any length available) |
| Conveying Speed | 0 – 30 m/min (standard) | ✔ Yes (0 – 80 m/min) |
| Load Capacity | 50 kg/m – 200 kg/m | ✔ Yes (up to 500 kg/m) |
| Belt Material | PVC-120 / PU / Rubber / Silicone / Modular plastic | ✔ Yes (FDA grade optional) |
| Motor Power | 0.75 kW – 22 kW | ✔ Yes |
| Incline / Decline Angle | 0° – 24° (standard rubber belt) | ✔ Yes (up to 90° with cleated belt) |
| Frame Material | Carbon steel (painted) | ✔ Yes (SS304, SS316, aluminum) |
| Voltage | 380V / 400V / 415V, 50/60Hz, 3-phase | ✔ Yes (custom voltage available) |
| Operating Temperature | -10°C – +50°C | ✔ Yes (heat/cold resistant belt) |
| Control Type | Manual start/stop | ✔ Yes (PLC + HMI, inverter speed control) |
Application
-
Mining and quarrying (ore, coal, sand, gravel)
-
Cement and aggregate plants
-
Food and beverage processing (FDA belt options)
-
Packaging and carton handling lines
-
Warehousing and logistics (sorting and distribution)
-
Assembly lines in automotive, electronics, and appliance manufacturing
-
Agriculture (grain, seed, fertilizer)
-
Chemical and fertilizer industries
Customization
We offer complete customization for every belt conveyor machine:
-
Belt width, total length, and conveying height
-
Belt type: smooth, chevron, cleated, sidewall, magnetic, wire mesh, modular plastic
-
Frame material: carbon steel (painted), stainless steel 304/316, aluminum profile
-
Motor power, gearbox ratio, and speed control (fixed or variable frequency drive)
-
Incline or decline angle, with or without cleats/side skirts
-
Control system: manual, push-button, PLC + touchscreen, remote control
-
Add-ons: belt scale, dust cover, magnetic separator, hopper, side guide rails
-
Custom RAL color for frame
-
Explosion-proof motor for hazardous environments
-
Mobile or fixed type
Feature
-
Energy-efficient drive system with low power consumption
-
Heavy-duty steel frame for long service life
-
Quick belt release and tension adjustment system
-
Anti-slip belt surface (optional chevron or cleated belt)
-
Sealed idler rollers for dust protection
-
Emergency stop cord along entire length
-
Low noise and smooth operation
-
Easy maintenance with modular design
-
Optional inverter for stepless speed adjustment
Support and Services
-
24/7 online technical support
-
Free conveyor layout design assistance
-
On-site installation and commissioning (optional)
-
Operator training and documentation included
-
12-month warranty + lifetime spare parts supply
-
OEM/ODM service for special requirements
-
Fast shipping of wear parts (belt, rollers, pulleys)
Packing and Shipping
-
Packing:
-
Belt, frame, and rollers: wrapped with stretch film + waterproof PE cover
-
Small parts (motors, controls, pulleys): export plywood case
-
All packed with anti-rust oil and foam padding
-
-
Shipping:
-
FOB / CIF / EXW by sea, air, rail, or express (door-to-door optional)
-
Delivery time: 15–45 working days depending on customization level
-
FAQ
Q: Can you make a custom length and width conveyor?
A: Yes, every conveyor belt machine is fully customizable in length, width, belt type, and frame material.
Q: What materials can be conveyed?
A: Powders, granules, boxes, bags, parts, ores, food products, etc. We customize belt material accordingly.
Q: Do you offer a food-grade conveyor?
A: Yes, we provide FDA-approved PU/PVC belts and stainless steel frames for food applications
