Customizable Multi-Purpose Microwave Drying Production Line for Energy Saving Industrial Sterilization & Dehydration
Datos del producto:
| Lugar de origen: | Porcelana |
| Nombre de la marca: | OSMANUV |
| Certificación: | ISO9001 |
| Número de modelo: | Especificación |
Pago y Envío Términos:
| Cantidad de orden mínima: | 1 juego |
|---|---|
| Precio: | Negociable |
| Detalles de empaquetado: | Envasado de madera |
| Tiempo de entrega: | 30-45 días |
| Condiciones de pago: | T/T |
| Capacidad de la fuente: | Negociación |
|
Información detallada |
|||
| Nombre del producto: | Microondas al vacío, horno al vacío, máquina deshidratadora de dátiles rojos con microondas tipo tún | Color: | Plata, según lo solicite, gris, etc., verde |
|---|---|---|---|
| Fuente de calefacción: | calentamiento por microondas, electricidad, secado por microondas, aire caliente | Uso: | Reducir la humedad del material, microondas industrial, secado y esterilización de frutas. |
| Instalación: | Guía del ingeniero,Fácil,Guía del ingeniero | Frecuencia microondas: | 2450MHz, 2450±50MHz |
| Grado de vacío: | <133Pa,≤10Pa | ||
Descripción de producto
Customizable Microwave Drying Production Line, Multi-Purpose Industrial Microwave Sterilization & Dehydration System
Product Overview
This industrial microwave drying production line uses volumetric heating to dry materials evenly from inside out, significantly reducing drying time compared to conventional hot air drying. Suitable for food, herbs, wood, chemical powders, and ceramic cores. The entire line supports customizable length, belt speed, microwave power (20kW-200kW+), and number of zones.
Technical Parameters
| Parameter | Standard Range | Customizable Option |
|---|---|---|
| Microwave power | 20kW - 200kW | ✔ Up to 500kW |
| Belt width | 500 - 2000 mm | ✔ Custom width |
| Drying temperature | 40°C - 120°C | ✔ 120°C - 200°C |
| Production capacity | 50 - 3000 kg/h | ✔ Depends on material |
| Number of heating zones | 2 - 8 zones | ✔ Up to 12 zones |
| Control system | PLC + HMI | ✔ Remote monitoring / IoT |
| Power supply | 380V / 50Hz (3-phase) | ✔ 220V / 60Hz / 415V |
| Microwave leakage | <1 mW/cm² (safe) | ✔ Stricter standard |
Applications
- Food industry: drying of nuts, fruit slices, meat jerky, pet food
- Chemical materials: pigments, catalysts, ceramic powders
- Wood & bamboo: sterilization and drying
- Agricultural products: garlic slices, mushroom, spices
All applications support customizable inlet moisture content and target final moisture.
Customization Options
- Line layout (straight / L-shape / split modules)
- Belt material (PTFE / mesh / ceramic rollers)
- Microwave power per zone
- Explosion-proof design for solvent-based materials
- Vacuum or inert gas drying option
- Automated feeding and packaging integration
Key Features
- Uniform drying without hot spots
- Energy saving - 30-50% less energy than hot air drying
- Low temperature operation preserves nutrients and color
- Instant on/off - no preheating required
- Small footprint compared to conventional dryers
- Real-time power adjustment per zone
Support and Services
- Free material testing lab report
- On-site installation & commissioning
- Operator training (video or in-person)
- 12-month warranty + lifetime remote technical support
- Spare parts supply (including magnetrons, belts, fuses)
Packing and Shipping
- Packing: Steel frame + anti-rust film + plywood export case (IP54 protection)
- Shipping: FOB/CIF from Shanghai or Ningbo port
- Lead time: 20-35 days based on customization level
- Shipping documents: Commercial invoice, packing list, CE certificate, operation manual
Frequently Asked Questions
Can you customize the line for high-moisture materials (>60%)?
Yes, we can add pre-drying and multi-stage microwave zones - customizable dehydration curve.
What is the minimum order quantity?
One complete production line, with customizable power from 20kW.
Does microwave drying affect product quality?
No, because low-temperature drying preserves vitamins, color, and active ingredients.
Is training included after installation?
Yes, local or remote training is available - customizable training schedule.
